RAYSHAPE

Ideal imaging conditions, even in turbid samples like tissue, are every microscopist’s dream. However, specimens are often inhomogeneous, and, what’s more, embedding and immersion media are hardly ever perfectly index-matched. Refractive-index mismatches compromise the focusing capabilities of your microscope and can give rise to low-resolution and poor-quality images.

abberior’s RAYSHAPE dynamic aberration correction solves this problem. Using adaptive optics with a deformable mirror, it puts diverted rays back on track, guaranteeing bright and crisp images from top to bottom and regardless of embedding medium, immersion medium, or specimen. Correction happens dynamically on-the-fly and leaves nothing to desire for your results.

Background-free MATRIX STED image of actin in microvilli of Caco2 cells

MATRIX Detector

Many eyes see more than one. The MATRIX detector drastically improves signal-to-background ratio, resolution, and dynamic range.

Details >

TIMEBOW Imaging

TIMEBOW lifetime imaging for stunning results at confocal and STED super-resolution.

Details >

Neurons stained for spectrin and adducine

FLEXPOSURE Illumination

Brings down the light dose on your sample and lables dramatically. Key ingredient for volume and live-cell superresolution.

Details >

xz section of a stage 17 Drosophila embryo, stained for chitin and DNA

RAYSHAPE Mirror

Dynamic aberration correction with a deformable mirror over about 200 µm z-range. 140 digital actuators adjust the mirror surface within milliseconds.

Details >

Meiotic cell of Chinese spring wheat stained for two synaptonemal complex components. TRUESHARP STED image.

TRUESHARP Deconvolution

TRUESHARP image boosting is next level deconvolution.

Details >

Axial STED image of actin in mouse inner ear hair cells

EASY3D

3D-STED and aberration control, the easy way

Details >

Three-color STED image of microtubules, myosin and actin in the growth cone of a neuron's axon

RAINBOW Detection

Continuously variable spectral detection.

Details >

STED Lasers

All-pulsed STED lasers for maximum resolution and minimal bleaching.

Details >

Autoalignment

Every beam in order, including pinhole and STED-shape

Details >

Autofocus

Continuous focus-lock, even with STED

Details >

Excitation Lasers

Pulsed excitation lasers for virtually every wavelength.

Details >

Accessories

Things to make your life easier

Details >

Custom upright 3D STED microscope by abberior

Custom Solutions

We offer solutions for even the most challenging applications. Everything that can be done, we will do.

Details >

FAQ Video 40

How does RAYSHAPE aberration correction work?”

Watch >

FAQ Video 25

“What is required for tissue imaging?”

Watch >

Hello RAYSHAPE

Bye-bye, aberrations!

The deeper you dive into the sample, the more severe the aberrations become, and the more you have to correct. In order to achieve zero aberrations throughout the sample, you therefore need to permanently adjust the amount of correction as focus depth changes.

RAYSHAPE vs

correction collar

Picture 1
RAYSHAPE preserves resolution and brightness over the whole sample depth of about 200 µm by dynamically redirecting aberrated light to the right places.

In comparison, mechanical optics using a correction collar can only correct a limited z-range of approximately 20 µm …

For correction collar images click on the slider arrow and see the difference

RAYSHAPE vs

correction collar

Picture 2
In this example (Stage 17 Drosophila embryo) a correction collar objective lens is set to correct aberrations at three different z-positions: close to the cover slip …

RAYSHAPE vs

correction collar

Picture 3
… at the middle of the z-range …

RAYSHAPE vs

correction collar

Picture 4
… and at the end. None of the positions is right for the whole sample and only a small z-range looks good.

RAYSHAPE vs

correction collar

Picture 5
Overview image of this stage 17 Drosophila embryo stained for chitin (abberior LIVE 610, green) and DNA (abberior LIVE 550, cyan).

RAYSHAPE deformable mirror

only from abberior

Deformable mirrors are adaptive elements with a flexible reflective surface. 140 digitally controlled actuators adjust the mirror’s surface within milliseconds, making RAYSHAPE exceptionally precise and allowing fast z-scans with continuous adjustment of the correction to compensate for aberrations at every depth.

With RAYSHAPE, you are not forced to choose a limited region of correction while the rest of the image stays blurred, as is the case for even motorized correction collar objectives. Once adjusted to the sample, RAYSHAPE automatically follows the focus as it moves through the specimen and dynamically corrects aberrations at different depths. The focus is kept stable and image acquisition runs completely autonomously for bright, high-resolution images even very deep in the sample.

Tissue imaging has never felt better than with RAYSHAPE.

RAYSHAPE deformable mirror with 140 actuators

RAYSHAPE deformable mirror with 140 actuators

Without RAYSHAPE the focus is aberrated

RAYSHAPE with its deformable mirror keeps the focus over the entire depth range

Mismatch between sample and the immersion medium of the objective lens results in a misshaped focal spot. To make things worse, sample inhomogeneities add to these aberrations. RAYSHAPE aberration correction compensates for these distortions by putting all rays in the right place and thus restores a perfect focus.

A deformable mirror acts as adaptive optics element to create a perfect wavefront
On its way to the detector the aberrated fluorescence is corrected

Correction of exitation STED

Correction of aberration fluorescence

Undistorted wavefronts entering the sample from the objective lens are normally spherical, but variations of the refractive index can distort them, leading to an imperfect focus. RAYSHAPE’s deformable mirror effectively cancels these aberrations. Applying the correct mirror shape for a specific aberration – which is a negative of the distortions introduced by the sample – achieves two things at once:

1) The wavefront of excitation and STED beam are altered to pre-compensate for aberrations. The focus is thus brought back to perfect shape.

2) The distorted wavefront of the fluorescence is also corrected before it reaches the detector.

Since RAYSHAPE can adjust the degree of correction fast and dynamically as the focus moves through the sample, the result is a clear image with strong signal and resolution from top to bottom.

Imaging a fluorescent bead layer at different depths (63x WI objective lens, TDE embedding). The deformable mirror automatically follows when focusing depth is changed. Brightness and resolution are largely preserved up to the working distance of the objective lens.

  • Up to five times higher signal in thick sample sections
  • Superior resolution with STED
  • Often the enabler for 3D-STED imaging
  • Automatic tracking of spherical aberrations
  • Correction of higher order aberrations (astigmatism, coma, trefoil, …)

Super-sharp images, even in thick samples

Axial STED image of actin in mouse inner ear hair cells

EASY3D

3D-STED and aberration control, the easy way

Details >
